Lab Test Vibration Sieve

Your Professional Lab Test Vibration Sieve Supplier

Zhengzhou Generate Machinery Co., Ltd. is a professional provider of vibrating, conveying, and lifting equipment, as well as other related machinery. Our primary products include various types of vibrating screens and conveyors, such as rotary vibrating screens, test sieves, belt conveyors, modular conveyors, roller conveyors, slat conveyors, bucket elevators, and various extruders, among others.

Extensive Experience

With over 30 years of experience in sales, we have established ourselves as a reliable partner in the industry.

Expert Team

Our team comprises experienced designers and engineers with extensive expertise in design, manufacturing, and debugging. They are capable of fulfilling all your specialized requirements.

Global Sales Market

Our products are exported to numerous regions worldwide, including Europe, America, the Middle East, and Southeast Asia.

Comprehensive Services

We provide integrated services encompassing design, layout planning, system integration, installation, and project management for clients globally.

Technical Parameters

Sieve Material	Stainless steel, Carbon steel or as your requirements
Mesh size	As you need
Machine diameter	200mm, 300mm, 400mm or as you need
Technology	Woven or as you need
Frame Material	Brass , Stainless Steel ,etc.
Frame Height (full)	1-3/4'' -- 2-5/8''
Aperture shape	Square or round
Mesh opening /Aperture	5--500mesh 10--200μm
Motor Power	0.18KW/As you need
Noise	< 50DB
Vibration Frequency	1440 times/min
Power supply	220V/50HZ or 380V/60HZ or as you need
Amplitude	0-3mm/Others
CE	Yes

Features of Lab Test Vibration Sieve

● Compact and portable design
● Guarantee low noise operation and high speed operation
● Energy efficient equipment
● Uses a flame proof motor material
● Made from high grade stainless steel
● Better dust handling capability
● Many screen options such as double or triple
● Easy to dismantle and clean
● Adjustable vibratory motion
● Sturdy and robust design
● Easy to install and operate
● Design should allow for easy and fast changing of sieves
● Guarantee high performance
● Durable to guarantee a long service lifespan thereby reducing maintenance costs

Applications of Lab Test Vibration Sieve

01/

Particle grading and screening
According to the screening effect of different particle sizes of particle materials on the screen, the particle materials are divided into different levels, so as to achieve the classification and classification of particles. This is important in industries where material properties and applications need to be controlled based on particle size, such as building materials industry, mining industry and chemical industry.

02/

Powder analysis and screening
Lab test vibrating screen can sieve fine powder materials to obtain powder samples with different particle size distributions. By analysis and screening, the important data such as the average particle size, particle size distribution and particle number in different particle size ranges can be determined, which provides a basis for the preparation and application of powder materials.

03/

Particle morphology and size analysis
Lab test vibrating screen can analyze the shape and morphological characteristics of the particles by observing the distribution of the particles on the screen. This is of great significance for understanding and studying the morphology and surface properties of granular materials, such as roundness, smoothness, porosity and other parameters.

04/

Screening efficiency and capacity analysis of granular materials
You can further understand the performance and operation indicators of the lab test vibrating screen by measuring and calculating the screening efficiency and capacity during the screening process. In practical applications, selecting the appropriate sieves and adjusting the screening parameters can improve the screening efficiency and capacity to meet different application needs.

Safety Precautions for Operating Lab Test Vibration Sieves

Develop and implement standard operating procedures (SOPs): Establish clear, written guidelines for the safe operation and maintenance of lab test vibration sieves to ensure operator consistency.

Communicate hazards and safety information: Clearly display warning signs, labels, or instructions near the lab test vibration sieve to inform operators of potential risks and safe operating practices.

Maintain a safe distance: Establish and enforce a minimum safe distance for workers not directly involved in operating or maintaining the lab test vibration sieve. This can help prevent injuries caused by accidental contact with the equipment during operation.

Conduct regular equipment inspections: Schedule routine inspections of lab test vibration sieves to identify and address potential safety concerns, wear, or damage before they escalate into more significant issues.

Provide ongoing training: Offer refresher training courses or safety briefings to ensure that all operators and maintenance personnel stay up-to-date on proper procedures and safety practices.

Plan for emergencies: Develop and implement emergency response plans in case of accidents or equipment malfunctions, including the designation of emergency shutdown procedures and first-aid supplies.

Install safety guards and barriers: Equip the lab test vibration sieve with guards, covers, or barriers to protect operators from moving parts or flying debris during operation.

Ordering Process

productcate-1-1

Packaging and Shipping

Packaging	Plastic bags and wooden cases will be needed when packing. We will have to make sure that they are not be damaged during their transfer.
Shipping	It could be shipped by sea, by air or by express(EMS, UPS, DHL, TNT, FEDEX and ect). Please confirm with us before placing orders.

Other Services Provided

Accepted Delivery Terms

FOB, CFR, CIF, EXW

Accepted Payment Currency

USD, EUR, JPY, CAD, AUD, HKD, GBP, CNY, CHF

Accepted Payment Type

T/T, L/C, D/P D/A, MoneyGram, Western Union, Cash, Escrow

Language Spoken

English, Chinese, Spanish, Russian

Our Factory

We have factories in Shanghai and Dalian which produce different conveying products to meet different requests of customers. If you are interested in us, we will welcome you to visit us at any time. Then you can know our quality and production capacity.

FAQ

Q: What is a lab test vibration sieve?

A: A lab test vibration sieve is a small screening device used in a laboratory environment. It uses mechanical vibration to classify granular materials according to particle size. It is mainly used in scenarios such as material particle size analysis, formula development, and quality control.

Q: How to use test sieves?

A: The sieve analysis starts with the smallest mesh size; the undersize is determined by weighing the material before and after sieving. If a size distribution curve is required, this procedure is continued with increasing mesh sizes. The oversize on the finer sieve is put on the sieve next in size and is sieved again.

Q: How accurate is a test sieve?

A: Statistical calculations confirm, to a minimum confidence level of 99%, that the standard deviation of these openings meets ASTM or ISO specifications. Thus, inspection sieves are ideal for applications where accuracy and repeatability are critical.

Q: Can lab test vibration sieves be used to screen liquid or slurry materials?

A: Most lab test vibration sieves are designed for dry screening. If you need to process liquids or slurries, you need to choose wet screening accessories (such as stainless steel screen + flushing device).

Q: How to install a lab test vibration sieve?

A: Place it on a horizontal surface to ensure that the base of the equipment is stable. Stack the screens from large to small (coarse on top and fine on bottom) according to the mesh size, with a receiving tray on the bottom layer and a cover on the top layer to prevent dust.

Q: How to clean a lab test vibration sieve?

A: After shutting down, remove the screen and use a soft brush to remove residual material. Equipment that comes into contact with food or medicine needs to be wiped with alcohol to avoid cross contamination.

As one of the leading lab test vibration sieve manufacturers and suppliers in China, we warmly welcome you to buy hot sale lab test vibration sieve for sale here from our factory. All machines are with high quality and competitive price.
