Rotary Vibrating Screen

Your Professional Rotary Vibrating Screen Supplier

Zhengzhou Generate Machinery Co., Ltd. is a professional provider of vibrating, conveying, and lifting equipment, as well as other related machinery. Our primary products include various types of vibrating screens and conveyors, such as rotary vibrating screens, test sieves, belt conveyors, modular conveyors, roller conveyors, slat conveyors, bucket elevators, and various extruders, among others.

Extensive Experience

With over 30 years of experience in sales, we have established ourselves as a reliable partner in the industry.

Expert Team

Our team comprises experienced designers and engineers with extensive expertise in design, manufacturing, and debugging. They are capable of fulfilling all your specialized requirements.

Global Sales Market

Our products are exported to numerous regions worldwide, including Europe, America, the Middle East, and Southeast Asia.

Comprehensive Services

We provide integrated services encompassing design, layout planning, system integration, installation, and project management for clients globally.

Technical Parameters

Type	ZGM-600	ZGM-800	ZGM-1000	ZGM-1200	ZGM-1500	ZGM-1800	ZGM-2000
Diameter	600mm	800mm	1000mm	1200mm	1500mm	1800mm	2000mm
Effective Screening Area	0.22m2	0.41m2	0.63m2	0.95m2	1.53m2	2.27m2	2.83m2
Voltage	110V/220V/380V/415V/Customized as you need
Material	Stainless steel 304, stainless steel 316, carbon steel and so on
Mesh Size	2~325 Mesh/Inch
Layers	1~4	1~3	1~3	1~3	1~2	1~2	1
Power	0.37KW	0.55KW	0.74KW	1.5KW	2KW	2.2KW	2.5KW
We can customize for you if you can tell your detailed requirements.

Advantages of Rotary Vibrating Screen

01/

High screening accuracy and better product quality
Through multi-level screen design and adjustable vibration parameters, the equipment can accurately separate materials with different particle sizes, reduce the phenomenon of over-screening or clogging, ensure the purity of the finished product, and meet the stringent requirements for fine screening in pharmaceutical, food and other industries.

02/

Dramatic increase in productivity
High-efficiency rotary vibrating screen adopts advanced vibration motor and dynamic balancing technology, screening speed far exceeds the traditional equipment, the processing capacity can be increased by 30%-50% per unit time, especially suitable for large-scale continuous production demand, significantly reduce the time cost.

03/

Energy Conservation and Environmental Benefits
The optimized power system consumes less energy and saves more than 20% of electricity than traditional screening equipment, while the fully enclosed structure reduces the escape of dust, which meets the green production standard and helps the enterprise to achieve the goal of sustainable development.

04/

Widely applicable and flexibly adaptable
From coarse screening of ore and coal to fine filtration of powder and liquid, the equipment can be adapted to different materials by replacing the screen mesh or adjusting the rotational speed, which is multi-purpose and highly cost-effective. The ability to achieve precise cut points in high efficiency rotary vibrating screens is a valuable advantage that impacts product quality.

Applications of Rotary Vibrating Screen

Abrasive & Ceramics: Alumina, quartz sand, mud, spray soil particles.

Chemical: Resin sand, pigment, washing powder, micro powder, paint, soda ash, lemon powder, rubber, and plastics.

Food: Sugar, salt, soda, MSG (monosodium glutamate), milk powder, soybean milk, yeast, juice, soy sauce, vinegar, etc.

Paper Making: Coating, coated slurry, black-and-white liquid, waste liquor, papermaking liquid, wastewater recycling.

Metallurgy: Titanium oxide, zinc oxide, electromagnetic materials, metal powder, welding rod powder, titanium oxide, etc.

Pharmaceutical: TCM (traditional Chinese medicine) powder, TCM liquid, western medical powder, western medical liquid, TCM & western medical particles, etc.

Environment Protection: Rubbish, excrement, waste oil, food effluent, wastewater processing, etc.

Precautions for Using Rotary Vibrating Screen

Selection of sieve hole
The size of the sieve hole determines the particle size distribution of the material. The smaller the sieve hole, the smaller the particles that can be screened out. Therefore, when selecting the sieve hole, it is necessary to make a reasonable choice according to the particle size requirements of the material.

Material feeding method
In order to ensure that the material can be evenly distributed on the screen surface, the feeding should be uniform and continuous, and not excessive, so as not to cause the screen to be blocked.

Control of screening time
Too long screening time will cause materials to accumulate on the screen surface, affecting the screening effect; too short screening time may result in incomplete screening. Therefore, we need to reasonably control the screening time according to the characteristics of the material and the screening requirements.

Clean the screen
The screen is easily blocked by the deposition of materials, which affects the screening effect. Therefore, during the screening process, cleaning the screen in time to keep the screen holes unobstructed can effectively improve the screening efficiency.

Ordering Process

Firstly, send us your detailed requirements(Conveyor types, sizes, applications)by Email, Alibaba, etc.

Then we will provide our best solution and quotation as per your requirements.

Once order confirmed and payment done, we will arrange production immediately.

Finally, goods will be send by sea/air/express etc.

Packaging and Shipping

Packaging	Wooden boxes will be used when we pack the rotary vibration screen. Then we can ship it by truck to the port such as Qingdao, Shanghai.
Shipping	It could be shipped by sea, by air or by express(EMS, UPS, DHL, TNT, FEDEX and ect). Please confirm with us before placing orders.

Other Services Provided

Accepted Delivery Terms

FOB, CFR, CIF, EXW

Accepted Payment Currency

USD, EUR, JPY, CAD, AUD, HKD, GBP, CNY, CHF

Accepted Payment Type

T/T, L/C, D/P D/A, MoneyGram, Western Union, Cash, Escrow

Language Spoken

English, Chinese, Spanish, Russian

Our Factory

We have factories in Shanghai and Dalian which produce different conveying products to meet different requests of customers. If you are interested in us, we will welcome you to visit us at any time. Then you can know our quality and production capacity.

FAQ

Q: What is the principle of vibrating screens?

A: Vibration screen machines apply the principle of vibration generation to sort materials. They work via a counterbalance or a shaft, but unbalanced movements can cause failures. Screens, set in decks with decreasing hole sizes, filter small rocks while retaining larger ones.

Q: How do you maintain a vibrating screen?

A: Ensure it is clean and properly tensioned, and free from damage or wear. If loose, increase the tension equally on both sides. Replace any worn or damaged screen media or bar rail liners.

Q: What is the rpm of a vibrating screen?

A: High-frequency vibrating screens usually operate at an inclined angle, traditionally varying between 0° and 25° and can go up to a maximum of 45°. They should operate with a low stroke and have a frequency ranging from 1500 to 9000 RPM.

Q: What is the efficiency of a vibrating screen?

A: According to the determined ranges,efficiency should be in the range of 90%-95% with respect to the above formula. Feed rate is the main parameter dictating efficiency. If the flow rate is below the capacity of the media, the runs idle so no s carried out.

Q: How do I increase the amplitude of my vibrating screen?

A: The amplitude of vibration can be altered by changing the position of the movable counterweight. Such adjustment is performed based on the application. The screening of coarse material demands a higher amplitude than the amplitude required for the classification of fines.

Q: How do you control feed rate to the vibrating screen?

A: Distribute the feed material evenly across the full width of the screen deck to maximize the effective screening area. Use feed distributors, chutes, or baffles to promote a uniform layer of material on the screen surface.

As one of the leading rotary vibrating screen manufacturers and suppliers in China, we warmly welcome you to buy hot sale rotary vibrating screen for sale here from our factory. All machines are with high quality and competitive price.
